Ball Float Drain Trap

Product Description



• Air Traps for Moisture Removal
• BEP Ball Float Auto drain traps are simple & reliable in operation.
• The plug valve type discharge orifice of BEP Traps ensures safe, efficient & maintenance free operation.
• Thanks to the simple float mechanism manufactured from high grade corrosion resistant stainless steel.
• Which guarantees the smooth separation of moist0ure from compressed air or pressurised gases with absolutely zero air gas leakage.
• BEP ball float auto drains are available for very low pressure as low as 0.01 Bar & for high pressure up to 315 Bar.
• BEP Ball Float Traps can be used for compressed air & pressurised gases like Oxygen, Hydrogen, Nitrogen, CO2, CNG, Natural gas etc.
• Pressure Range - up to 315 Bar.
• Size - 15mm to 100mm
• End Conn - Screwed / Socket Weld End / Flanged.
• For more information of material of construction / Size please refer the Product Details

Advantages

• Only one moving part.
• Simple system, working parts manufactured from high grade corrosion resistant stainless steel.
• Insensitive to contamination.
• Extremely long working life.
• Extremely low maintenance.
• Proportional control action.
• Independent of pressure and temperature fluctuations.
• Impact-free and silent condensate discharge in exact quantity.
• No whirlpool effect, consequently no loss of steam.
• Can work even at 95% back pressure.
• Can work at very low differential pressure i e at 0.01 Kg/cm2.
• Any standard trap of PN 13 range can work upto 13 Kg/cm2 differential pressure i.e low inventory



Reliable Drainage for Steam and Gas Lines

The Ball Float Drain Trap is designed to handle condensate efficiently in demanding industrial applications. Its float-operated mechanism ensures automatic operation for both horizontal and vertical installations. With a unidirectional flow, robust construction, and diverse model sizes, it effectively prevents water hammer and maintains operational efficiency in steam and gas pipelines.


Durable Construction and Wide Compatibility

Manufactured using premium SS304/SS316 and cast iron, this trap is equipped with a bolted cover for secure sealing. Suitable for high-pressure environments (up to 16 bar), it features anti-corrosive coatings and a soft or metal seat for enhanced longevity. Available in flanged or screwed connections, it easily adapts to various pipeline standards including BSP/NPT threads.


Compliant, Tested, and Easy to Maintain

Adhering to ISI and ISO standards, every unit undergoes rigorous body pressure testing at 32 bar. Spares are readily available, supporting quick maintenance and long-term reliability. The painted or shot-blasted surface treatment and cylindrical shape contribute to its resilience against harsh industrial conditions.
