Baffle Steam Moisture Separators

Price 20000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Baffle Steam Moisture Separators Specification

Air Discharge
High Efficiency Moisture Removal

Noise Level
Low

Power Consumption
Nil

Condition
New

Material
CS/SS (Carbon Steel / Stainless Steel)

Power Source
No Power Required

Dimensions
As per Model

Configuration
Baffle Type, Vertical Orientation

Mute
Yes

Air Flow Capacity
Varies with Model

Driven Method
Pipeline Mounted

Working Presssure
Up to 16 Bar

Separator Efficiency
99% removal of entrained water droplets above 10 microns

Operating Temperature
Up to 230C

Connection Type
Flanged / Screwed / Socket Weld

Surface Finish
Painted / Polished

Installation
Vertical installation recommended

Corrosion Resistance
Yes

Maintenance
Low, Easy to Clean

End Connection Size
1/2\\

Application
Steam Lines, Process Equipment, Heat Exchangers

About Baffle Steam Moisture Separators

BEP Baffle Type Moisture Separator with vertical / horizontal design are available for Steam application with negligible pressure drop. Automatic drain with isolation valve can be provided as per the requirement.
Pressure Range - Up to 63 Kg/Cm2
Sizes - 25mm to 300mm
Media - Steam

Exceptional Moisture Removal Efficiency

Baffle Steam Moisture Separators provide superior moisture separation, capturing 99% of water droplets above 10 microns. This ensures optimal steam purity, protecting downstream equipment and improving system performance. The separators vertical, baffle-type configuration fosters effective droplet settling, maintaining high efficiency and reliability across a range of industrial applications.

Versatile Installation and Durable Construction

Engineered for flexible installation, these moisture separators accommodate various connection typesflanged, screwed, or socket weldsupporting a spectrum of pipe sizes. Their construction from carbon steel or stainless steel guarantees robust corrosion resistance. With a painted or polished surface finish, these separators withstand demanding operating environments, making them suitable for diverse industries.

Low Maintenance and Energy Efficiency

Designed for ease of use, Baffle Steam Moisture Separators are simple to clean and require minimal upkeep. Since they are pipeline-mounted and operate without an external power source, operational costs remain low. The units low noise output further reduces workplace disturbances, while their highly efficient moisture removal capability maximizes process safety and efficiency.

FAQs of Baffle Steam Moisture Separators:

Q: How do Baffle Steam Moisture Separators achieve high moisture removal efficiency?

A: These separators use a baffle-type configuration that directs steam through strategically positioned plates, causing water droplets above 10 microns to separate out. This process ensures up to 99% efficiency in removing entrained moisture from steam, protecting downstream equipment from damage.

Q: What are the recommended installation guidelines for these moisture separators?

A: A vertical installation is recommended for optimal performance. The units are available in flanged, screwed, or socket weld connections, allowing compatibility with most piping systems ranging from 1/2 to 12 and above.

Q: When should I consider using a Baffle Steam Moisture Separator in my system?

A: These separators are essential whenever high-quality, dry steam is requiredespecially for steam lines, process equipment, and heat exchangers. They help prevent issues caused by moisture, such as reduced heat transfer, corrosion, and equipment wear.

Q: Where can Baffle Steam Moisture Separators be applied?

A: They are suitable for various industrial applications, including steam lines, heat exchangers, and process equipment, wherever there is a need to remove moisture from steam to safeguard systems and improve efficiency.

Q: What is the maintenance process for these separators?

A: Maintenance is straightforward due to the simple design. The separators are easy to clean, require minimal servicing, and are constructed from corrosion-resistant materials like carbon steel or stainless steel, contributing to their longevity.

Q: How does using this separator benefit my process operations?

A: By eliminating excess water from steam, these separators enhance system reliability, reduce corrosion, improve heat exchange efficiency, lower maintenance costs, and prolong the lifespan of downstream equipment.

Q: Do these moisture separators require any external power source for operation?

A: No external power source is needed. The separators are pipeline mounted and operate solely by steam flow dynamics, which eliminates power consumption and makes installation more flexible.
